• Full Bore.
• Standard Pattern.
• Teflon Seats and Seals.
• Lever Operated.

• Steam

The Trap should be installed horizontally with flow direction as indicated on the valve . the trap should be below the drainage point of the equipment. Float always rises & falls vertically in horizontal plane. For correct working of trap, the arrow on the name plate should be indicating in vertically downwards direction.
